Posted on June 06, 2026Aluminium Clad Steel wire sits at the intersection of mechanical and electrical engineering: it bears tension like steel and conducts like aluminium. That dual character is why it appears across the overhead power and telecom supply chain. Below are the principal applications for Systematic’s ACS wire, with the specification considerations for each.
1. Core wire for ACSR / ACSR-AW conductors
ACS wire replaces galvanized steel as the strength core in aluminium-conductor designs, giving better corrosion life than galvanized steel core wire for ACSR. Higher-conductivity grades (27–40% IACS) also let the core carry part of the current.
2. OPGW (Optical Ground Wire) stranding
ACS wire forms the stranded outer layers of OPGW cables, surrounding the central optical-fibre tube. It provides the short-circuit current capacity and tensile strength the earth-wire function requires while resisting corrosion over decades on the tower. See how this fits the full build in OPGW cable construction and specifications.
3. Overhead ground / earth wires
As a standalone shield wire, ACS protects transmission lines from lightning while grounding fault current — the corrosion-resistant cladding is critical for a wire exposed at the highest point of the structure.
4. EHV transmission and self-damping conductors
Extra-high-voltage lines and self-damping / bare overhead conductors use ACS where long spans demand a high strength-to-weight ratio.
5. Messenger, guy and hardware wires
ACS is also used for messenger wires, guy wires, and formed wires for terminating and splicing lines, plus fencing, barbed wire and general hardware.
Selecting the right ACS grade per application
| Application | Typical priority |
| ACSR core / guy / messenger | Strength bias (14–20% IACS) |
| OPGW stranding | Balanced strength + short-circuit capacity (20–30%) |
| Ground/earth wire, EHV | Conductivity bias (30–40% IACS) |
To match a grade to your conductor design, review the ACS wire specifications or request a data sheet.
Frequently Asked Questions
Is ACS wire used in OPGW?
Yes. ACS wire is stranded around the central fibre tube in OPGW cables, providing tensile strength and short-circuit current capacity. See OPGW construction.
Can ACS replace galvanized steel core in ACSR?
Yes — ACS is used as a corrosion-resistant, optionally current-carrying alternative to galvanized steel core wire in ACSR/AW conductors.
What makes ACS suitable for outdoor power lines?
The aluminium cladding resists moisture and oxidation, and the steel core provides the tensile strength needed for long overhead spans.
