Welded Wire Mesh Size Chart & Specifications Guide

Welded Wire Mesh Size Chart & Specifications Guide

Posted on April 04, 2026

Welded wire mesh (also called weldmesh or jali) is a grid of steel wires resistance-welded at every intersection, producing rigid panels and rolls used in reinforcement, fencing, gabions and industrial screening. The right specification depends on three numbers — wire diameter, aperture (mesh opening) and roll size. This chart sets out the manufacturing range produced by Systematic Ltd and the standards each product conforms to.

Welded wire mesh manufacturing range

Parameter	Minimum	Maximum
Wire diameter	2.00 mm	8.00 mm
Aperture (section of roll)	25 mm	200 mm
Roll width	900 mm (3 ft)	2,700 mm (9 ft)

Source: Systematic Ltd welded wire mesh manufacturing data.

Raw material grades: Mild Steel wire, Galvanized (GI) wire, Stainless Steel wire and High-Carbon wire. Standards: IS 1566, IS 432 (Part II)/1982/2002, BS 4482/1969 and BS 4483/1969. Galvanized wire is specified where corrosion resistance is required — for the GI variant and its uses, see GI wire mesh applications.

How to read the specification

• Wire diameter drives strength and weight. 2.0–3.0 mm suits plaster reinforcement and light screening; 4.0–8.0 mm suits structural reinforcement, security panels and gabions.
• Aperture (25–200 mm) controls what the mesh contains or filters: small apertures for fine screening and safety guarding, large apertures for reinforcement and stone-fill gabions.
• Roll width (900–2,700 mm) determines panel coverage and offcut wastage on site.

Reinforcement mesh designation

For concrete and pavement reinforcement, welded mesh is specified by area designation. The standard “252 mesh” denotes a square mesh providing 252 mm²/m of longitudinal wire area, supplied in 4.8 m × 24 m fabric sheets to IS 1566 / IS 432 — increasingly used in place of hand-tied TMT bars for slabs and road pavements.

Common applications by specification

Application	Typical wire / aperture	Grade
Plaster / crack-control reinforcement	2.0–3.0 mm, 25–50 mm	GI / MS
Slab & pavement reinforcement	Per 252-type designation	MS / high-carbon
Security & perimeter panels	4.0–8.0 mm, 50–100 mm	GI
Gabions & erosion control	Heavy-gauge, large aperture	GI (heavy zinc)
Machine guarding & screening	2.0–4.0 mm, 25–50 mm	GI / SS

For mesh used specifically in boundary fencing, see the welded wire mesh fencing guide, and to compare mesh fencing types, the GI mesh fencing comparison guide.

Packaging

Rolls are supplied in stretch-film/plastic wrapping or HDPE sheet; sheets are stretch-film wrapped and mounted on wooden pallets for transit protection.

To order against a drawing or BOQ, view the full welded wire mesh product specifications or request a quote.
